2 MP ColorVu Dual-light Fixed Turret Camera
DS-2CE70DF0T-LMFS
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- Up to 20 m IR distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP67)
Технические параметры
Available modelsDS-2CE70DF0T-LMFS(2.8mm), DS-2CE70DF0T-LMFS(3.6mm)
Тип корпусаTurret
Разрешение
Тип объективаФиксированный
Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
ИК расстояние21-50m
Focal Length & FOV2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 126°3.6 mm, horizontal FOV: 84°, vertical FOV: 46°, diagonal FOV: 98°
WDRDWDR
Тип объектива2.8 mm and 3.6 mm fixed focal lens
Уровень освещенностиNormal
Iris Type2.8 mm and 3.6 mm fixed focal lens
Уровень защитыIP67
МатериалМеталл
Lens mountM12
Supplement Light TypeIR,White Light
Supplement Light RangeIR: Up to 20 m,White Light: Up to 20 m
Smart Supplement LightYes
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementDWDR,BLC,HLC,Global
Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness, Sharpness, Anti-banding, AGC
Power12 VDC ± 25%, max. 2.9 W,*You are recommended to use one power adapter to supply the power for one camera.
МатериалMetal
DimensionØ85.11 mm × 77.62 mm (Ø3.35" × 3.05")
WeightApprox. 320 g (0.71 lb.)
LanguageEnglish
ProtectionIP67
White BalanceAuto, Manual
Signal SystemPAL/NTSC
Day/Night ModeAuto/Color/BW (Black and White)
Noise Reduction3D DNR/2D DNR
КоммуникацияHIKVISION-C
