DS-2XM6736G0-IM/ND(C)

3MP Mobile Dome Camera

High quality imaging with 3 MP resolution
2/2.8/4/6/8 mm fixed lens
Three streams
Clear imaging against strong back light due to 120 dB WDR technology
Efficient H.265+ compression technology
4 driving abnormal detection and object detection
Water and dust resistant (IP67) and vandal resistant(IK10)

Артикул: 3367

Технические параметры

Available modelsDS-2XM6736G0-IM/ND(6mm)(C), DS-2XM6736G0-IM/ND(4mm)(C), DS-2XM6736G0-IM/ND(2.8mm)(C), DS-2XM6736G0-IM/ND(2.0mm)(C), DS-2XM6736G0-IDM(2.0mm)(C)

ПодсерияMobile Network Camera(AE)

Focal Length & FOV2 mm, horizontal FOV 122.6°, vertical FOV 71.7°, diagonal FOV 139.9°2.8 mm, horizontal FOV 100.6°, vertical FOV 55.1°, diagonal FOV 117.4°4 mm, horizontal FOV 75.3°, vertical FOV 41.4°, diagonal FOV 88.2°6 mm, horizontal FOV 51.6°, vertical FOV 28.8°, diagonal FOV 59.5°8 mm, horizontal FOV 37.5°, vertical FOV 20.7°, diagonal FOV 43.3°

Aperture2 mm, F2.25,2.8/4/6 mm, F2.0, 8 mm, F1.6,

Lens mountM12

H.265 TypeMain Profile

Scalable Video Coding (SVC)H.264 and H.265 encoding

APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK

ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

User/HostUp to 32 users,3 levels: Administrator, Operator and User

Network StorageMicroSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANRTogether with high-end Hikvision memory card, memory card encryption and health detection are supported.

ClientiVMS-4200, Hik-Connect, Hik-Central

Web browserPlug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11Plug-in free live view: Chrome 45+, Mozilla Firefox52+

Day/Night SwitchDay/Night/Auto/Schedule

Image EnhancementBLC, HLC, 3D DNR

Image SettingsRotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser

Reset KeyYes

Ethernet Interface1 RJ45 10M/100M Ethernet port

Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

Smart EventLine crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection, Object detection: detects faces and upload images

LinkageUpload to FTP/NAS/memory card, notify monitoring center, send email, trigger recording, trigger capture

Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)

General FunctionAnti-flicker, 3 streams, heartbeat, mirror, privacy mask

Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz

Day & NightIR Cut Filter

H.264 TypeMain Profile/High Profile

Environment Noise FilteringYes

Shutter Speed1/3 s to 1/100,000 s

Alarm1 input, 1 output (12 VDC, 30 mA)

Audio1 built-in mic, mono sound

Slow ShutterYes

DNR3D DNR

Camera DimensionCamera: Φ 110 mm × 57.4 mm (4.3″ × 2.26″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″)With package: 252 mm × 160 mm × 95 mm (9.9″ × 6.3″ × 3.7″)

Wide Dynamic Range120 dB

Camera WeightCamera: Approx. 460 g (1 lb.)With package: 900 g (2 lb)

Power Consumption and Current-IDS: 24 VDC, 0.3 A, max. 7.5 W-IS/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W-IDM: 24 VDC, 0.3 A, max. 7.5 W-IM/ND: PoE: (802.3af, 36V to 57V), 0.30 A to 0.20 A, max: 7.5W
