4 MP Darkfighter Varifocal Dome Network Camera
DS-2CD3D46G2T-IZHSY
- High quality imaging with 4 MP resolution
- Efficient H.265+ compression technology
- Anti-IR Reflection
- Motorized varifocal lens for easy installation and monitoring
- False alarm reduction through human and vehicle target classification based on deep learning
- Clear imaging against strong backlight due to 140 dB WDR technology
- Audio and alarm interface available
- Water and dust resistant (IP67) and vandal-resistant (IK10)
- Anti-Corrosion — NEMA 4X: NEMA 250-2014
Технические параметры
Available modelsDS-2CD3D46G2T-IZHSY(2.8-12mm), DS-2CD3D46G2T-IZHSU(8-32mm)(H), DS-2CD3D46G2T-IZHSU(2.8-12mm)(H), DS-2CD3D46G2T-IZHSUY(8-32mm)(H), DS-2CD3D46G2T-IZHSUY(2.8-12mm)(H)
Подсерия3 Series
Тип корпусаDome
Разрешение
Тип объективаМоторизованный варифокальный
Shutter Time1/3 s to 1/100, 000 s
WDR120 dB, 140 dB
Focal Length & FOV2.8 to 12 mm, horizontal FOV 115° to 42°, vertical FOV 59° to 24°, diagonal FOV 141° to 48°8 to 32 mm, horizontal FOV 42° to 15°, vertical FOV 23° to 9°, diagonal FOV 49° to 17°
Тип объективаVarifocal lens, motorized lens, 2.8 to 12 mm and 8 to 32 mm optional
Iris TypeVarifocal lens, motorized lens, 2.8 to 12 mm and 8 to 32 mm optional
Aperture2.8 to 12 mm: F1.28 to 32 mm: F1.7
Lens mountIntegrated
DORI2.8 to 12 mm: D: 60 m to 149 m, O: 23 m to 59 m, R: 12 m to 29 m, I: 6 m to 14 m8 to 32 mm: D: 150 m to 400 m, O: 59 m to 158 m, R: 30 m to 80 m, I: 15 m to 40 m
Supplement Light TypeIR
Supplement Light Range2.8 to 12 mm: up to 40 m8 to 32 mm: up to 60 m
Smart Supplement LightYes
H.265 TypeMain Profile
Bit Rate ControlCBR/VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)5 fixed regions for main stream and sub-stream
AIЕсть, Защита периметра
APIOpen Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
Локальный выводCVBS, N/A
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP
Съемка при слабом освещенииDarkfighter
User/HostUp to 32 users. 3 user levels: administrator, operator and user
Расстояние освещения21-50m, 51-100m
SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for Open Network Video Interface, memory card encryption, SFTP encryption, SRTP encryption
Тип хранилищаEMMC, SD Карта
Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200, Hik-Connect, Hik-Central
Web browserPlug-in required live view: IE 10, IE 11Plug-in free live view : Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)140 dB
Day/Night SwitchDay, Night, Auto, Schedule
Image EnhancementBLC, HLC, 3D DNR
Image Parameters SwitchYes
Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
SNR≥ 52 dB
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection, video tampering alarm, exception
Smart EventLine crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))Unattended baggage detection, object removal detection, scene change detection, audio exception detection
LinkageUpload to NAS/memory card/FTP, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning
Power12 VDC ± 25%, 0.9 A, max. 10.8 W, two-core terminal block24 VAC ± 20%, 0.75 A, 50/60 Hz, max. 10.8 WPoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
DimensionØ162 × 141.8 mm (Ø6.4" × 5.6")
WeightApprox. 1420 g (3.1 lb.)
With Package WeightApprox. 2058 g (4.5 lb.)
Storage Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionAnti-banding, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
EMCFCC (47 CFR Part 15, Subpart B)CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)RCM (AS/NZS CISPR 32: 2015)IC (ICES-003: Issue 7)KC (KN32: 2015, KN35: 2015)
SafetyUL (UL 62368-1)CB (IEC 62368-1: 2014+A11)CE-LVD (EN 62368-1: 2014/A11: 2017)LOA (IEC/EN 60950-1)BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
EnvironmentCE-RoHS (2011/65/EU)WEEE (2012/19/EU)Reach (Regulation (EC) No 1907/2006)
ProtectionIP67 (IEC 60529-2013)IK10 (IEC 62262: 2002)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Day & NightIR cut filter
IR Wavelength850 nm
H.264 TypeBaseline Profile/Main Profile/High Profile
Environment Noise FilteringYes
Built-in Microphone-U: Yes
Depth of Field2.8 to 12 mm: 1.5 m to ∞8 to 32 mm: 1.5 m to ∞
Alarm2 inputs, 2 outputs (max. 24 VDC, 1 A; 24 VAC, 1 A)
Audio1 input (line in), max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
Face CaptureYes
Fourth Stream50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)*Fourth stream is supported under certain settings.
Target CroppingYes
Anti-Corrosion Protection-Y: NEMA 4X: NEMA 250-2014
