2MP AcuSense Moto Varifocal Bullet Camera
DS-2CD3A26G2T-IZS
- High quality imaging with 2 MP resolution
- 15 × optical zoom captures details in remote area
- Excellent low-light performance with powered-by-DarkFighter technology
- Focus on human and vehicle targets classification based on deep learning
- Clear imaging against strong back light due to 120 dB WDR technology
- Efficient H.265+ compression technology
- Audio and alarm interface available
- Water and dust resistant (IP67) and vandal-resistant (IK10)
Технические параметры
Available modelsDS-2CD3A26G2T-IZS(4.7-71mm)
Подсерия3 Series
Тип корпусаBullet
Разрешение
Тип объективаМоторизованный варифокальный
Shutter Time1 s to 1/30,000 s
Focal Length & FOV4.7 to 71 mm, horizontal FOV: 57.7° to 3.66°, vertical FOV: 33.2° to 2.75°, diagonal FOV: 65.2° to 4.58°
WDR120 dB
Тип объективаVarifocal lens, motorized lens, 4.7 to 71 mm
Iris TypeVarifocal lens, motorized lens, 4.7 to 71 mm
ApertureF1.6
Lens mountIntegrated
DORIWide: D: 73.5 m (247 ft), O: 29.2 m (95.8 ft), R: 14.7 m (48.2 ft), I: 7.4 m (24.3 ft)Tele: D: 1517.2 m (4977.7 ft), O: 602.1 m (1975 ft), R: 303.4 m (994.1 ft), I: 151.7 m (497.7 ft)
Supplement Light TypeIR
Supplement Light RangeUp to 150 m
Smart Supplement LightYes
H.265 TypeMain Profile
Bit Rate ControlCBR/VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)5 fixed regions for main stream and sub-stream
APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
AIЕсть
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP, SRTP, WebSocket, WebSockets, etc.,
Съемка при слабом освещенииPowered by Darkfighter
User/HostUp to 32 users. 3 user levels: administrator, operator and user
Расстояние освещения51-100m
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2, host authentication (MAC address)
Тип хранилищаSD Карта
Network StorageMicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200, Hik-Connect, Hik-Central
Web browserPlug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)120 dB
Day/Night SwitchDay, Night, Auto, Schedule
Image EnhancementBLC, HLC, 3D DNR
Image Parameters SwitchYes
Image SettingsSaturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
SNR≥ 52 dB
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection (human and vehicle targets classification), video tampering alarm, exception
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection, scene change detection, audio exception detection
LinkageUpload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, audible warning
Power12 VDC ± 25%, 0.9 A, max. 10.8 W,24 VAC ± 20%, 0.75 A, max. 10.8 W,PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W,two-core terminal block
Dimension144 mm × 140 mm × 349.2 mm (5.7" × 5.5" × 13.7")
WeightApprox. 1835 g (4.1 lb.)
With Package WeightApprox. 2875 g (6.3 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionAnti-banding, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
EMCFCC: 47 CFR Part 15, Subpart B,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,KC: KN32: 2015, KN35: 2015
SafetyUL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005
EnvironmentCE-RoHS: 2011/65/EU
ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Day & NightIR cut filter
IR Wavelength850 nm
H.264 TypeBaseline Profile/Main Profile/High Profile
Audio TypeMono sound
Environment Noise FilteringYes
Depth of Field2.6 m to ∞
Alarm2 input, 2 output (max. 24 VDC, 1 A)
Audio1 input(s) (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output(s) (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Face CaptureYes
Fourth Stream50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)*Fourth stream is supported under certain settings.
Target CroppingYes
Min. Focus DistanceW: 0.7 m (2.3 ft)T: 20 m (65.6 ft)
Центр загрузки
Firmware Firmware_V5.7.0_220720
