2 MP AcuSense Varifocal Dome Network Camera
DS-2CD3726G2T-IZS
- High quality imaging with 2 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Clear imaging against strong back light due to 120 dB true WDR technology
- Efficient H.265+ compression technology
- False alarm reduction through human and vehicle target classification based on deep learning
- Water and dust resistant (IP67) and vandal-resistant (IK10)
- 3D DNR technology delivers clean and sharp images
- Motorized varifocal lens for easy installation and monitoring
Технические параметры
Available modelsDS-2CD3726G2T-IZS(2.7-13.5mm)(C), DS-2CD3726G2T-IZS(7-35mm)(C)
Подсерия3 Series
Тип корпусаDome
Разрешение
Тип объективаМоторизованный варифокальный
Shutter Time1/3 s to 1/100,000 s
Focal Length & FOV2.7 to 13.5 mm: horizontal FOV 113° to 34°, vertical FOV 58° to 19°, diagonal FOV 138° to 39°7 to 35 mm: horizontal FOV 30° to 11°, vertical FOV 17° to 6°, diagonal FOV 34° to 13°
WDR120 dB
Тип объективаVarifocal lens, motor-driven lens, 2.7 to 13.5 mm and 7 to 35 mm optional
Iris TypeVarifocal lens, motor-driven lens, 2.7 to 13.5 mm and 7 to 35 mm optional
Aperture2.7 to 13.5 mm: F1.47 to 35 mm: F1.6
Lens mount2.7 to 13.5 mm: Ø147 to 35 mm: Integrated
DORI2.7 to 13.5 mm: D: 44 to 129 m, O: 17 to 51 m, R: 8 to 25 m, I: 4 to 13 m7 to 35 mm: D: 137 to 400 m, O: 54 to158 m, R: 27 to 80 m, I: 13 to 40 m
Supplement Light TypeIR
Supplement Light Range2.7 to 13.5 mm: up to 40 m7 to 35 mm: up to 50 m
Smart Supplement LightYes
H.265 TypeMain Profile
Bit Rate ControlCBR/VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)5 fixed regions for main stream and sub-stream
APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
AIЕсть, Защита периметра
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP, WebSocket, WebSockets
Съемка при слабом освещенииPowered by Darkfighter
User/HostUp to 32 users. 3 user levels: administrator, operator and user
Расстояние освещения21-50m, 51-100m
SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Тип хранилищаSD Карта
Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200, Hik-Connect, Hik-Central
Web browserPlug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Wide Dynamic Range (WDR)120 dB
Day/Night SwitchDay, Night, Auto, Schedule
Image EnhancementBLC, HLC, 3D DNR
Image Parameters SwitchYes
Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
SNR≥ 52 dB
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection (human and vehicle targets classification), video tampering alarm, exception
Smart EventUnattended baggage detection, object removal detection, scene change detection, audio exception detection
LinkageUpload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, audible warning
Power12 VDC ± 25%, 0.9 A, max. 10.8 W, Ø5.5 mm coaxial power plugPoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
DimensionØ153.3 mm × 111.6 mm (Ø6.0" × 4.4")
WeightApprox. 895 g (1.9 lb.)
With Package WeightApprox. 1930 g (3.2 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languagesEnglish, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionAnti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
ProtectionIP67 (IEC 60529-2013), IK10 (IEC 62262:2002)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Day & NightIR cut filter
IR Wavelength850 nm
H.264 TypeBaseline Profile/Main Profile/High Profile
Environment Noise FilteringYes
Alarm2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
Audio1 input (line in), max input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), max output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
Face CaptureYes
Fourth Stream50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)*Fourth stream is supported under certain settings.
Target CroppingYes
Perimeter ProtectionLine crossing detection, intrusion detection, region entrance detection, region exiting detection
Центр загрузки
Firmware Firmware_V5.7.12_230131
