6 MP AcuSense Varifocal Bullet Network Camera
DS-2CD3666G2-IZS
- Supports Hikvision Embedded Open Platform (HEOP) and importing third party applications
- Supports 1.5 Tops computing power, 40 MB system memory, 350 MB smart RAM, and 2 GB eMMC storage for sharing resources
- High quality imaging with 6 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong backlight due to 120 dB true WDR technology
- False alarm reduction through human and vehicle target classification based on deep learning
- Audio and alarm interface available
- Motorized varifocal lens for easy installation
- Water and dust resistant (IP66) and vandal-resistant (IK10)
Технические параметры
Available modelsDS-2CD3666G2-IZS(2.7-13.5mm)(H), DS-2CD3666G2-IZS(7-35mm)(H)
Подсерия3 Series
Тип корпусаBullet
Разрешение6 MP
Тип объективаМоторизованный варифокальный
Shutter Time1/3 s to 1/100,000 s
Focal Length & FOV2.7 to 13.5 mm: horizontal FOV 106° to 35.6°, vertical FOV 55.9° to 20°, diagonal FOV 127.4° to 40.8°7 to 35 mm: horizontal FOV 34.4° to 12.5°, vertical FOV 19° to 7.1°, diagonal FOV 39.8° to 14.3°
WDR120 dB
Тип объективаVarifocal lens, motorized lens, 2.7 to 13.5 mm and 7 to 35 mm optional
Iris TypeVarifocal lens, motorized lens, 2.7 to 13.5 mm and 7 to 35 mm optional
Aperture2.7 to 13.5 mm: F1.6; 7 to 35 mm: F1.6
Lens mount2.7 to 13.5 mm: Ø14; 7 to 35 mm: Integrated
DORI2.7 to 13.5 mm: D: 68 to 200 m, O: 27 to 79 m, R: 13 to 40 m, I: 6 to 20 m7 to 35 mm: D: 218 to 580 m, O: 86 to 230 m, R: 43 to 116 m, I: 21 to 58 m
Supplement Light TypeIR
Supplement Light Range2.7 to 13.5 mm: up to 60 m; 7 to 35 mm: up to 80 m
Smart Supplement LightYes
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)5 fixed regions for main stream and sub-stream
APIONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
AIЕсть
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP, WebSocket, WebSockets, SRTP
Съемка при слабом освещенииNormal
User/HostUp to 32 users3 user levels: administrator, operator, and user
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Расстояние освещения21-50m
Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Тип хранилищаSD Карта
ClientiVMS-4200,Hik-Connect,Hik-Central
Web browserPlug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Wide Dynamic Range (WDR)120 dB
Day/Night SwitchDay,Night,Auto,Schedule
Image EnhancementBLC,HLC,3D DNR,Defog
Image Parameters SwitchYes
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
SNR≥ 52 dB
Privacy Mask4 programmable polygon privacy masks
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), scene change detection,audio exception detection,defocus detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
Power12 VDC ± 25%, 1.08 A, max. 13 W,two-core terminal block,reverse polarity protection,PoE: IEEE 802.3at, Class 4, max. 15 W
МатериалAluminum alloy body
DimensionØ144 mm × 332 mm (Ø5.7" × 13.1")
WeightApprox. 1535 g (3.4 lb.)
With Package WeightApprox. 2581 g (5.7 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter
ДругоеHEOP
EMCCE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
SafetyUL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
EnvironmentCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
ProtectionIP66: IEC 60529-2013,IK10: IEC 62262:2002
Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Day & NightIR cut filter
IR Wavelength850 nm
H.264 TypeBaseline Profile,Main Profile,High Profile
Environment Noise FilteringYes
Alarm1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Audio1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Face CaptureYes
Fourth Stream50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
Target CroppingYes
People CountingYes
Open ResourcesMemory: 40 MB,Smart RAM: 350 MB,eMMC: 2 GB
Computing Power1.5 TOPS
Deep Learning StructureCaffe,PyTorch,TensorFlow,PaddlePaddle, ONNX
Programming LanguageC,C++
Open CapabilityHEOP 2.0 OpendevSDK
