4MP DeepinView Moto Varifocal Bullet Camera
iDS-2CD7A45G0-IZ(H)S(Y)
- High quality imaging with 4 MP resolution
- 25 × optical zoom captures details in remote area
- Clear imaging against strong back light due to 140 dB WDR technology
- Efficient H.265+ compression technology to save bandwidth and storage
- Built-in heater on the front viewing window to ensure clear image under snowy weather
- Built-in gyroscope to ensure stable image output
- Water and dust resistant (IP67) and vandal proof (IK10)
Технические параметры
Available modelsiDS-2CD7A45G0-IZHS(4.7-118mm), iDS-2CD7A45G0-IZS(4.7-118mm), iDS-2CD7A45G0-IZHSY(4.7-118mm)
Подсерия7 Series
Тип корпусаBullet
Разрешение
Тип объективаМоторизованный варифокальный
Shutter Time1 s to 1/30,000 s
Focal Length & FOV4.7 to 118 mm, horizontal FOV 58° to 2.8°, vertical FOV 32.3° to 1.6°, diagonal FOV 63° to 3°
WDR120 dB, 140 dB
Aperture4.7 to 118 mm: F1.6 to F3.8
DORIWide:D: 106 m, O: 42.1 m, R: 21.2 m, I: 10.6 mTele:D: 2200 m, O: 873 m, R: 440 m, I: 220 m
Supplement Light TypeIR
Supplement Light RangeUp to 200 m
Smart Supplement LightYes
H.265 TypeMain Profile
Bit Rate ControlCBR/VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)4 fixed regions for each stream
AIЕсть, Защита периметра
APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Локальный выводCVBS
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Съемка при слабом освещенииPowered by Darkfighter
User/HostUp to 32 users3 user levels: administrator, operator, and user
Расстояние освещения101-300m
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
Тип хранилищаSD Карта
Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200, Hik-Connect, Hik-Central
Web browserPlug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 12+ Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)140 dB
Day/Night SwitchDay, Night, Auto, Schedule
Image EnhancementBLC, HLC, Defog, 3D DNR
Image Parameters SwitchYes
Image SettingsSaturation, brightness, contrast, sharpness, white balance, and AGC adjustable by client software or web browser
SNR≥ 52 dB
Privacy Mask8 programmable polygon privacy masks, mask color or mosaic configurable
RS-485With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection
Smart EventLine crossing detection, intrusion detection, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))Scene change detection, audio exception detection, defocus detection
LinkageUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
Power-IZHSY: 12 VDC ± 20%, 1.73 A, max. 20.7 W, three-core terminal block24 VAC ± 20%, 1.31 A, max. 19.9 W, three-core terminal blockPoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.46 A to 0.35 A, max. 19.5 W-IZHS: 12 VDC ± 20%, 1.62 A, max. 19.4 W, two-core terminal block24 VAC ± 20%, 1.21 A, max. 18.7 W, two-core terminal blockPoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.43 A to 0.32 A, max. 18.2 W-IZSY: 12 VDC ± 20%, 1.13 A, max. 13.48 W, three-core terminal block24 VAC ± 20%, 0.89 A, max. 12.14 W, three-core terminal blockPoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.22 A to 0.29 A, max. 12.29 W-IZS:12 VDC ± 20%, 1.02 A, max. 12.22 W, two-core terminal block24 VAC ± 20%, 0.8 A, max. 11.49 W, two-core terminal blockPoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.20 A to 0.26 A, max. 10.50 W
DimensionWith -Y: Ø140 mm × 378.4 mm (Ø5.5" × 14.9") Without -Y: Ø144.1 mm × 375.2 mm (Ø5.7 × 14.8"")"""
WeightWith -Y: Approx. 2160 g (4.8 lb.)Without -Y: Approx. 2130 g (4.7 lb.)
With Package WeightWith -Y: Approx. 3310 g (7.3 lb.)Without -Y: Approx. 3200 g (7.1 lb.)
Storage ConditionsWithout -H: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)With -H: -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function5 streams, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014);RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7); KC (KN 32: 2015, KN 35: 2015)
SafetyUL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1)
EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
ProtectionIK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
Day & NightIR cut filter
IR Wavelength850 nm
H.264 TypeBaseline Profile/Main Profile/High Profile
Audio TypeMono sound
Environment Noise FilteringYes
FocusAuto, semi-auto, manual
Image StabilizationEIS (Built-in gyroscope to improve EIS performance)
Alarm2 inputs, 2 outputs (max. 24 VDC, 1 A)
Audio1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
Face Capture1. Detects up to 60 faces simultaneously2. Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°3. Uploads face with background and closed-up face pictures
Fourth Stream50 Hz: 25 fps (704 × 576, 640 × 480)60 Hz: 30 fps (704 × 480, 640 × 480)
Fifth Stream50 Hz: 25 fps (704 × 576, 640 × 480)60 Hz: 30 fps (704 × 480, 640 × 480)
Target CroppingYes
e-PTZSupports Patrol and Auto-tracking settings
Face ComparisonUp to 10 face libraries. Up to 30,000 faces for each library. 150,000 faces in total. Supports face library encryption
Anti-Corrosion ProtectionWith -Y: NEMA 4X(NEMA 250-2018)
ДругоеPVC FREE
HeaterYes
De-icingYes
