2-inch 2 MP Fixed Powered by DarkFighter IR Network Speed Dome
PTZ-N2C200C-DE
- High quality imaging with 2 MP resolution
- Clear imaging against strong back light due to DWDR technology
- 3D DNR technology delivers clean and sharp images
- HiLookVision cloud service and APP for remote management and views of devices
- Built-in microphone and speakerfor real-time audio security
- Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Water and dust resistant IP66
Технические параметры
Available modelsPTZ-N2C200C-DE(F0), PTZ-N2C200C-DE(F1)
ПодсерияNetwork Dome HiLook Series
Разрешение
ИК расстояние21-50m
Уровень освещенностиColorVu
Уровень защитыIP66
ApertureF1.0
Supplement Light TypeWhite Light
Supplement Light RangeWhite Light Distance: up to 30 m
Smart Supplement LightYes
H.265 TypeMain Profile
APIOpen Network Video Interface, ISAPI, SDK
ProtocolsIPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementBLC, HLC, 3D DNR
Image SettingsSaturation, brightness, contrast, sharpness
Оптический зум<10X
PoE поддержка802.3af
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection, video tampering alarm, exception
Power12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protectionPoE: (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, max. 10 W
WeightCamera weight: 780 g (1.7 lb.)With package weight: 1280 g (2.8 lb.)
General FunctionMirror, password protection, watermark
EMCFCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014; IC: ICES-003: Issue 7
ProtectionIP66 (IEC 60529-2013)
Audio Sampling Rate8 kHz/16 kHz
H.264 TypeBaseline Profile, Main Profile, High Profile
Environment Noise FilteringYes
Built-in MicrophoneYes
DimensionsCamera dimension: 162 mm × 120 mm × 234.2 mm (6.4" × 4.7" × 9.2"")Package dimension: 205 mm × 167 mm × 289 mm (8.1 × 6.6"" × 11.4"")"""
FOV2.8 mm, horizontal FOV 106.1°, vertical FOV 55.8°, diagonal FOV 126.5°4 mm, horizontal FOV 83.6°, vertical FOV 44.6°, diagonal FOV 99.1°
Movement Range (Pan)0° to 340°
Movement Range (Tilt)-5° to 105°
Pan SpeedPan speed: configurable from 4° to 21°/s
Tilt SpeedTilt speed: configurable from 4° to 19°/s
Alarm LinkageUpload to FTP, notify surveillance center, send email, upload to memory card
Built-in SpeakerYes
Центр загрузки
Firmware Firmware_V5.7.12_220819
