IPC-B180H

4K Fixed Bullet Network Camera

High quality imaging with 8 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
Water and dust resistant (IP67)
Easy installation with Power over Ethernet (PoE) technology

Артикул: 3579

Технические параметры

Available modelsIPC-B180H(2.8mm)(C)(HiLookSTD)/KIT

ПодсерияFixed-lens Camera

Тип корпусаBullet

Тип объективаФиксированный

Shutter Time1/3 s to 1/100,000 s

ИК расстояние21-50m

Focal Length & FOV2.8 mm, horizontal FOV 108°, vertical FOV 60°, diagonal FOV 127°4 mm, horizontal FOV 86°, vertical FOV 46°, diagonal FOV 102°

Тип объективаFixed focal lens, 2.8 and 4 mm optional

Уровень освещенностиNormal

Iris TypeFixed focal lens, 2.8 and 4 mm optional

Уровень защитыIP67

ApertureF2.0

Lens mountM12

DORI2.8 mm, D: 81 m, O: 32 m, R: 16 m, I: 8 m4 mm, D: 106 m, O: 42 m, R: 21 m, I: 11 m

Supplement Light TypeIR

Supplement Light RangeUp to 30 m

Smart Supplement LightYes

H.265 TypeMain Profile

Bit Rate ControlCBR/VBR

Region of Interest (ROI)1 fixed region for main stream

APIOpen Network Video Interface (Profile S), ISAPI, SDK

ProtocolsTCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, 802.1x, SMTP

User/HostUp to 32 users3 levels: Administrator, Operator and User

SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, security audit log, TLS 1.2, host authentication (MAC address)

ClientiVMS-4200, HiLookVision

Web browserPlug-in required live view: IE 10, IE 11Local service: Chrome 57.0+, Firefox 52.0+

Wide Dynamic Range (WDR)120 dB

Day/Night SwitchDay, Night, Auto, Schedule

Image EnhancementBLC, HLC, 3D DNR

Image SettingsMirror, rotate, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

SNR≥ 52 dB

Privacy Mask4 regions of privacy mask

Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

Basic EventMotion detection, video tampering alarm, exception

LinkageNotify surveillance center, trigger capture

Power12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5. mm coaxial power plugPoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

МатериалMetal & Plastic

Dimension184.1 mm × 66 mm × 69.1 mm (7.3" × 2.6" × 2.7")

WeightApprox. 270 g (0.6 lb.)

With Package WeightApprox. 489 g (1.1 lb.)

Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

LanguageEnglish, Ukrainian

General FunctionAnti-flicker, heartbeat, password protection, password reset via email

EMCFCC SDoC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014);RCM (AS/NZS CISPR 32: 2015)

SafetyCB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017)

EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

ProtectionIP67 (IEC 60529-2013)

Day & NightIR cut filter

IR Wavelength850 nm

H.264 TypeBaseline Profile/Main Profile/High Profile
