2MP Dual Light Audio Fixed Turret Camera
DS-2CE78D0T-LFS
- High quality imaging with 2 MP, 1920×1080 resolution
- Fixed focal lens, 2.8 mm and 3.6 mm optional
- Up to 40 m IR distance for bright night imaging
- Up to 20 m white light distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS）
- Water and dust resistant (IP67)
- High quality audio with audio over coaxial cable, built-in mic
Technical parameters
SubseriesD0T-LS Series
Available modelsDS-2CE78D0T-LFS(2.8mm), DS-2CE78D0T-LFS(3.6mm)
Case TypeTurret
Resolution
Lens TypeFixed Lens
Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
IR Distance21-50m
Focal Length & FOV2.8 mm, horizontal FOV: 100°, vertical FOV: 55°, diagonal FOV: 116°3.6 mm, horizontal FOV: 80°, vertical FOV: 43°, diagonal FOV: 95°
WDRDWDR
Lens TypeFixed focal lens, 2.8 mm and 3.6 mm optional
Illumination LevelNormal
Iris TypeFixed focal lens, 2.8 mm and 3.6 mm optional
Protection LevelIP67
MaterialPlastic&Metal
Lens mountM12
Supplement Light TypeWhite Light;IR
Supplement Light RangeIR : Up to 40 mWhite Light : Up to 20 m
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementYes
Image SettingsBrightness, Sharpness, Smart IR
MaterialBody: MetalEnclosure: Metal
Dimension97.9 mm × Ø110 mm (3.85" × Ø4.33")
WeightApprox. 340 g (0.75 lb.)
LanguageEnglish
ProtectionIP67
Day & NightICR
White BalanceAuto/Manual
AGCYes
ConsumptionMax. 3.5 W
Signal SystemPAL/NTSC
Day/Night ModeIR/White Light
CommunicationHIKVISION-C
