2MP Dual Light Audio Indoor Fixed Turret Camera
DS-2CE76D0T-LMFS
- High quality imaging with 2 MP, 1920×1080 resolution
- Up to 30 m IR distance for bright night imaging
- 2.8 mm, 3.6 mm fixed focal lens
- One port for four switchable signals (TVI/AHD/CVI/CVBS）
- Up to 20 m white light distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- Water and dust resistant (IP67)
Technical parameters
SubseriesD0T-LS Series
Available modelsDS-2CE76D0T-LMFS(2.8mm), DS-2CE76D0T-LMFS(3.6mm)
Case TypeTurret
Resolution
Lens TypeFixed Lens
Shutter TimePAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
IR Distance21-50m
Focal Length & FOV2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
WDRDWDR
Lens Type2.8 mm, 3.6 mm fixed focal lens
Illumination LevelNormal
Iris Type2.8 mm, 3.6 mm fixed focal lens
Protection LevelIP67
MaterialMetal
Lens mountM12
Supplement Light TypeWhite Light;IR
Supplement Light RangeIR : Up to 30 mWhite Light : Up to 20 m
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementYes
Image SettingsBrightness, Sharpness, Smart IR
MaterialMetal
Dimension80 mm × Ø85.1 mm (3.1" × Ø3.4")
WeightApprox. 296 g (0.65 lb.)
LanguageEnglish
ProtectionIP67
Day & NightICR
White BalanceAuto/Manual
AGCYes
ConsumptionMax. 3.3 W
Signal SystemPAL/NTSC
Day/Night ModeIR/White Light
CommunicationHIKVISION-C
