2MP ColorVu Audio Fixed Turret Camera
DS-2CE72DF0T-FS
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 40 m white light distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP67)
Technical parameters
SubseriesDF0T Series
Available modelsDS-2CE72DF0T-FS(2.8mm), DS-2CE72DF0T-FS(3.6mm)
Case TypeTurret
Resolution
Lens TypeFixed Lens
Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
IR Distance21-50m
Focal Length & FOV2.8 mm, horizontal FOV: 105°, vertical FOV: 55°, diagonal FOV: 125°3.6 mm, horizontal FOV: 84°, vertical FOV: 45°, diagonal FOV: 99°
WDRDWDR
Lens Type2.8 mm, 3.6 mm fixed focal lens
Illumination LevelColorVu
Iris Type2.8 mm, 3.6 mm fixed focal lens
Protection LevelIP67
MaterialPlastic&Metal
Lens mountM12
Supplement Light TypeWhite Light
Supplement Light RangeUp to 40 m
Smart Supplement LightYes
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementDWDR, BLC, HLC, Global
Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness, Sharpness, Anti-banding, AGC
Power12 VDC ± 25%, max. 3.2 W,*You are recommended to use one power adapter to supply the power for one camera.
MaterialEnclosure: Plastic, Main body: Metal
DimensionØ110 mm × 98.3 mm (4.33" × 3.87")
WeightApprox. 305 g (0.67 lb.)
LanguageEnglish
ProtectionIP67
AlarmSolid Light Alarm (White Light)
White BalanceAuto, Manual
Signal SystemPAL/NTSC
Day/Night ModeColor
Noise Reduction3D DNR/2D DNR
CommunicationHIKVISION-C
