2 MP ColorVu Dual-light Indoor Fixed Turret Camera
DS-2CE70DF0T-LPFS
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- Up to 20 m IR distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
Technical parameters
Available modelsDS-2CE70DF0T-LPFS(2.8mm), DS-2CE70DF0T-LPFS(3.6mm)
SubseriesDF0T Series
Case TypeTurret
Resolution
Lens TypeFixed Lens
Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
IR Distance0-20m
Focal Length & FOV2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 126°3.6 mm, horizontal FOV: 84°, vertical FOV: 46°, diagonal FOV: 98°
WDRDWDR
Lens Type2.8 mm and 3.6 mm fixed focal lens
Illumination LevelColorVu
Iris Type2.8 mm and 3.6 mm fixed focal lens
MaterialPlastic
Lens mountM12
Supplement Light TypeIR,White Light
Supplement Light RangeIR: Up to 20 m,White Light: Up to 20 m
Smart Supplement LightYes
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementDWDR,BLC,HLC,Global
Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness, Sharpness, Anti-banding, AGC
Power12 VDC ± 25%, max. 2.9 W,*You are recommended to use one power adapter to supply the power for one camera.
MaterialPlastic
DimensionØ85.02 mm × 81.25 mm (Ø3.35" × 3.2")
WeightApprox. 155 g (0.34 lb.)
LanguageEnglish
White BalanceAuto, Manual
Signal SystemPAL/NTSC
Day/Night ModeAuto/Color/BW (Black and White)
Noise Reduction3D DNR/2D DNR
CommunicationHIKVISION-C
