4MP Indoor Box Network Camera
DS-2CD3843G0-AP
Technical parameters
Subseries3 Series
Available modelsDS-2CD3843G0-AP
Case TypeBox
Resolution
Lens TypeMotorized Varifocal Lens
WDR120 dB
Lens mountC/CS mount
H.265 TypeMain Profile
Region of Interest (ROI)1 fixed region for main stream and sub-stream
APIOpen Network Video Interface, ISAPI
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
User/HostUp to 32 users. 3 levels: administrator, operator and user
Low-Light ImagingNormal
Storage TypeSD Card
Network StorageAuto network replenishment (ANR)
ClientiVMS-4200, Hik-Connect
Web browserPlug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)120 dB
Day/Night SwitchDay, Night, Auto, Schedule
Image EnhancementBLC, 3D DNR
Image SettingsSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
RS-4851 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection, video tampering alarm, exception
Smart EventLine crossing detection, intrusion detection
LinkageUpload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output
Power12 VDC ± 25%, 0.58 A, max. 7 W, two-core terminal block, reverse polarity protection,24 VAC ± 20%, 0.49 A, max. 7 W, two-core terminal blockPoE: 802.3af, 36 V to 57 V, 0.22 A to 0.14 A, max. 8 W
With Package WeightApprox. 947 g (2.1 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
EMCFCC (47 CFR Part 15, Subpart B)CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
SafetyCB (IEC 62368-1: 2014+A11)CE-LVD (EN 62368-1: 2014/A11: 2017)BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
EnvironmentCE-RoHS (2011/65/EU)
Audio Sampling Rate8 kHz/16 kHz
Day & NightIR cut filter
H.264 TypeBaseline Profile/Main Profile/High Profile
Environment Noise FilteringYes
Shutter Speed1/3 s to 1/100, 000 s
Web Client LanguageEnglish, Ukrainian
Alarm1 alarm in, 1 alarm out, (max. 24 VAC/24 VDC, 500 mA)
Audio1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium.
Camera Dimension69.8 mm × 58 mm × 137 mm (2.7" × 2.3" × 5.4")
Camera MaterialMetal
Camera WeightApprox. 585 g (1.3 lb.)
