Dual-Lens People Counting Network Camera
DS-2CD6825G0/C-IV(S)(B)
Technical parameters
Available modelsDS-2CD6825G0/C-IVS(2mm)(B), DS-2CD6825G0/C-IV(2mm)(B)
SubseriesDual-Lens People Counting Network Camera
Case TypeCube, Specialty
Resolution
Lens TypeMulti-Lens
Shutter Time1/25 s to 1/100,000 s
Focal Length & FOV2 mm, horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112°
WDR120 dB
Lens TypeFixed focal lens, 2 mm
Iris TypeFixed focal lens, 2 mm
ApertureF2.25
Lens mountM12
Supplement Light TypeIR
Supplement Light RangeUp to 6 m
H.265 TypeMain Profile
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)4 fixed region(s) for main stream and sub-stream
APIOpen Network Video Interface (Profile S, Profile G),ISAPI,SDK
AIPeople Counting, Yes
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Low-Light ImagingNormal
User/HostUp to 32 users3 user levels: administrator, operator, and user
Illumination Distance0-20m
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
Storage TypeN/A, SD Card
ClientiVMS-4200,Hik-Connect
Web browserPlug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+,Local service: Chrome 57.0+, Firefox 52.0+, Safari12+
Wide Dynamic Range (WDR)120 dB
Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger (-S)
Image EnhancementBLC,HLC,3D DNR,defog
Image SettingsSaturation,brightness,contrast,sharpness,adjustable by client software or web browser
RS-485-S: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
Power12 VDC ± 20%, 0.58 A, max. 7.0 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: 802.3af, Type 1, Class 3, 36 V to 57 V, 0.24 A to 0.15 A, max. 8.5 W
MaterialFront cover: plastic, camera body: metal
Dimension168 mm × 61 mm × 41 mm (6.6" × 2.4" × 1.6")
WeightApprox. 435 g (1 lb.)
With Package WeightApprox. 835 g (1.6 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 144 °F). Humidity 95% or less (non-condensing)
Language32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General FunctionHeartbeat,anti-flicker,mirror,password protection
EMCFCC: 47 CFR Part 15, Subpart B, IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3,AS/NZS CISPR 32:2015
SafetyUL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
EnvironmentCE-RoHS: 2011/65/EU+2015/863
ProtectionIP67: IEC 60529-2013
Audio Sampling Rate-S: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Day & NightIR cut filter
IR Wavelength850 nm
H.264 TypeBaseline Profile,Main Profile,High Profile
Audio Type-S: Mono sound
Environment Noise Filtering-S: Yes
Built-in MicrophoneYes
Alarm-S: 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A)
Audio-S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,-S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
People CountingCounts people entering and exiting separately Supports real-time uploading and uploading by statistic cycle Sends email reports on daily, weekly, monthly or annually basis Supports target filtering by height
