4K ColorVu Fixed Dome Network Camera
DS-2CD2187G2-L(SU)
- High quality imaging with 8 MP resolution
- Efficient H.265+ compression technology
- 24/7 colorful imaging
- Clear imaging against strong back light due to 130 dB WDR technology
- Focus on human and vehicle targets classification based on deep learning
- -SU: Built-in microphone for real-time audio security, audio and alarm interface available
- Water and dust resistant (IP67) and vandal resistant (IK10)
Technical parameters
Available modelsDS-2CD2187G2-L(2.8mm)(C), DS-2CD2187G2-L(4mm)(C), DS-2CD2187G2-LSU(2.8mm)(C), DS-2CD2187G2-LSU(4mm)(C), DS-2CD2187G2-LSU(2.8mm)(C)(BLACK)
SubseriesEasyIP 4.0 with ColorVu
Case TypeDome
Resolution
Lens TypeFixed Lens
Shutter Time1/3 s to 1/100,000 s
Focal Length & FOV2.8 mm, horizontal FOV 109°, vertical FOV 59°, diagonal FOV 130°4 mm, horizontal FOV 93°, vertical FOV 49°, diagonal FOV 111°
WDR130 dB
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Iris TypeFixed focal lens, 2.8 and 4 mm optional
ApertureF1.0
Lens mountM16
DORI2.8 mm, D: 84 m, O: 33 m, R: 16 m, I: 8 m4 mm, D: 102 m, O: 40 m, R: 20 m, I: 10 m
Supplement Light TypeWhite Light
Supplement Light RangeUp to 30 m
Smart Supplement LightYes
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)1 fixed region(s) for main stream and sub-stream
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
AIPerimeter Protection
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
Low-Light ImagingColorVu
User/HostUp to 32 users3 user levels: administrator, operator, and user
Illumination Distance21-50m
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)
Storage TypeSD Card
Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200,iVMS-5200,Hik-Connect
Web browserPlug-in required live view: IE10+,Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 12+,Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)130 dB
Day/Night SwitchDay,Night,Auto,Schedule
Image EnhancementBLC,HLC,3D DNR
Image Parameters SwitchYes
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
SNR≥ 52 dB
Privacy Mask4 regions of privacy mask
Reset KeyYes
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), scene change detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning (-SU), trigger alarm output (-SU), supplement light
Power12 VDC ± 25%, 0.6 A, max. 7 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3af, Class 3, max. 8.5 W
MaterialMetal
DimensionØ121.5 mm × 97.6 mm (Ø4.8 × 3.8")"""
WeightApprox. 540 g (1.2 lb.)
With Package WeightApprox. 735 g (1.6 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter,password protection,one-key reset,three streams
EMCFCC: 47 CFR Part 15, Subpart B,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
SafetyUL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,LOA: IEC/EN 60950-1
EnvironmentCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
Audio Sampling Rate-SU: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Day & Night24/7 color imaging
H.264 TypeBaseline Profile,Main Profile,High Profile
Audio Type-SU: Mono sound
Environment Noise Filtering-SU: Yes
Built-in Microphone-SU: Yes
Depth of Field2.8 mm: 3.1 m to ∞4 mm: 3.5 m to ∞
Alarm-SU: 1 input(s), 1 output(s) (max. 12 VDC, 30 mA)
Audio-SU: 1 input(s) (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output(s) (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Face CaptureYes
